R19 시리즈 유량계형 압력 조절기

/ 제품 / 스테인레스 스틸 압력 조절기 / R19 시리즈 유량계형 압력 조절기

R19 시리즈 유량계형 압력 조절기

R19는 압력 감소와 유량 측정을 교묘하게 통합하여 MIG/TIG 가스 차폐 용접 및 산업 실험실용으로 설계된 편리한 도구입니다. 핵심 기능은 충격 방지 복합 재료로 제작된 투명한 흐름 튜브로, 분당 리터(LPM)를 명확하게 표시하여 운영자에게 가스 소비량에 대한 명확한 개요를 제공합니다. 압력 조절기는 안전한 0.35MPa로 사전 설정되어 있으며 본체는 고품질 황동으로 단조 및 전기 도금되어 용접 환경에서 스패터와 스파크를 효과적으로 처리합니다. 이 통합 설계는 가스 연결을 단순화하고 누출 위험을 줄입니다.

  • 설명
  • 문의하기

모델 번호

가스 서비스

출구 유량계

입구 게이지(MPa)

입구 연결

콘센트 연결

R19C-25L

CO₂

0-25LPMCO₂

25

G5/8"-RH(F)

M16-1.5RH(M)

R19A-25L

아칸소

0-25LPM 아르곤

25

G5/8"-RH(F)

M16-1.5RH(M)

R19HE-80L

그는

0-80LPM 헬륨

25

G5/8"-RH(F)

M16-1.5RH(M)

R19A-50L

아칸소

0-50LPM 아르곤

25

G5/8"-RH(F)

M16-1.5RH(M)

R19HE-160L

그는

0-160LPM 헬륨

25

G5/8"-RH(F)

M16-1.5RH(M)

R19N-30L

N2

0-30LPM 질소

25

G5/8"-RH(F)

M16-1.5RH(M)

R19Q-30L

공기

0-30LPM 공기

25

G5/8"-RH(F)

M16-1.5RH(M)

R19H-100L

H2

0-100LPM 수소

25

W21.8-14LH(M)

M16-1.5RH(M)
