SR2 시리즈 스테인리스강 중유량 압력 조절기

/ 제품 / 스테인레스 스틸 압력 조절기 / SR2 시리즈 스테인리스강 중유량 압력 조절기

SR2 시리즈 스테인리스강 중유량 압력 조절기

SR2는 중간 유량이 필요한 가스 시스템을 위해 특별히 설계된 최적화된 내부 흐름 채널을 통해 1.1의 CV 값을 달성합니다. 또한 전기도금된 316L 스테인레스 스틸 본체와 상단 커버가 장착된 단일 스테이지 다이어프램 구조를 채택하여 표준 또는 특수 가스 공급 시 2차 오염이 발생하지 않도록 합니다. 견고한 1.6kg 구조는 더 높은 유량에서 우수한 기계적 충격 저항을 제공하며 입구 및 출구 포트 사양을 1/2" NPT(F)를 포함한 다양한 형태로 선택할 수 있어 시스템 적응성이 크게 향상됩니다. 코어 다이어프램 센서는 매우 민감하여 압력 변동에 대한 실시간 피드백과 신속한 보상을 제공하므로 적당한 흐름 안정성이 요구되는 반도체, 발전소, 탄광과 같은 산업 환경에 널리 적용할 수 있습니다.

  • 설명
  • 문의하기

시리즈

본체 포트

입구 압력

출구 압력

게이지

입구 커넥터

콘센트 커넥터

옵션

SR2

B

D

H

G

02

02

P

SR2L

(316L)

SR2B

(구리 전기도금)

A
B
G
J
M
Q

C:4000psi
D:3000psi
F:500psi

G:0-250psi
H:0-125psi
1:0-100psi
K:0-50psi
L:0-25psi
Q:30'HgVac-30psi
S:30"HgVac-60psi
T:30"HgVac-100psi
U:30"HgVac-200psi

G: MPa 테이블

P: Psi/bar 테이블

W: 압력계 없음

02:3/8"NPT(F)

03:3/8"NPT(M)

04:1/2"NPT(F)

05:1/2NPT(M)

12: 3/8" 카드 슬리브 커넥터

13: 1/2" 카드 슬리브 커넥터

다른 형태의 커넥터도 선택할 수 있습니다.

02:3/8"NPT(F)

03:3/8"NPT(M)

04:12"NPT(여)

05:12"NPT(M)

12: 3/8" 카드 슬리브 커넥터

13: 1/2" 카드 슬리브 커넥터

다른 형태의 커넥터도 선택할 수 있습니다.

P: 패널 설치

R: 안전 밸브
