SR4 시리즈 스테인레스 스틸 고압 압력 조절기

/ 제품 / 스테인레스 스틸 압력 조절기 / SR4 시리즈 스테인레스 스틸 고압 압력 조절기

SR4 시리즈 스테인레스 스틸 고압 압력 조절기

SR4는 최대 6000psi(약 41.4MPa)의 초고압 입력 요구 사항을 처리하도록 특별히 설계된 보다 견고한 피스톤형 감압 구조를 사용합니다. 다이어프램은 고압에서 피로 마모되기 쉽기 때문에 피스톤형 구조는 더 강력한 기계적 지지력과 매우 긴 사용 수명을 제공하므로 실험실 고압 테스트, 공정 제어 및 기류 정련과 같은 극한 환경에 특히 적합합니다. CV 값은 0.06으로 상대적으로 낮게 설정되어 있지만 출력 압력 조정 범위가 매우 넓으며 본체와 내부 부품 모두 316L 스테인리스 스틸로 제작되어 고순도 및 부식성 가스에 대한 화학적 불활성을 보장합니다. 시스템 통합 관점에서 볼 때 SR4는 고압 가스 실린더 컨테이너 터미널 감압 시스템의 핵심으로, 후속 처리 장치에 고압 가스를 안전하고 안정적으로 도입할 수 있습니다.

  • 설명
  • 문의하기

시리즈

BC디 부품

입구 압력

출구 압력

게이지

입구 커넥터

콘센트 커넥터

옵션

SR4

B

B

H

G

00

00

P

SR4L

(316L)

A

D

G

M

B:6000psi

D:3000psi

D:0-3000psi

E:0-1500psi

F:0-500psi

G:0-250psi

G: MPa 테이블

P: 프시브바 테이블

W: 압력계 없음

00:1/4"NPT(F)

01:1/4"NPT(M)

10: 1/8" 카드 슬리브 커넥터

11: 1/4" 카드 슬리브 커넥터

12: 3/8" 카드 슬리브 커넥터

15: 6mm 카드 슬리브 커넥터

16: 8mm 카드 슬리브 커넥터

다른 형태의 커넥터도 선택할 수 있습니다.

00:1/4"NPT(F)

01:1/4"NPT(M)

10: 1/8" 카드 슬리브 커넥터

11: 1/4" 카드 슬리브 커넥터

12: 3/8" 카드 슬리브 커넥터

15: 6mm 카드 슬리브 커넥터

16: 8mm 카드 슬리브 커넥터

다른 형태의 커넥터도 선택할 수 있습니다.

P: 패널 설치
