SR1 시리즈 스테인레스 스틸 소유량 압력 조절기

SR1은 정밀 단일 스테이지 다이어프램 감압 구조를 채택하여 고성능 스테인리스 스틸 다이어프램을 통한 압력 전달을 통해 매우 안정적인 출력 압력을 보장합니다. 다양한 고순도, 부식성, 유독성 가스를 자신있게 처리할 수 있습니다. 밸브 본체는 프리미엄 316L 스테인리스 스틸로 제작되고, 시트는 PCTFE 또는 PTFE로 제작되며, 다이어프램은 하스텔로이 또는 316L 스테인리스 스틸로 제작됩니다. 이 고급 소재 조합을 통해 -40°C ~ 74°C의 혹독한 온도에서도 탁월한 성능을 발휘합니다. 기술 매개변수는 경쟁이 매우 치열하며 CV 값은 0.08로 정밀하게 제어됩니다. 1.5배의 최대 입력 압력 안전 마진은 고압 환경에서 장기간 작동을 확실하게 보장하며, 0.9kg의 가벼운 디자인으로 유연한 패널 또는 벽면 장착이 가능합니다.

  • 설명
  • 문의하기

시리즈

본체 포트

입구 압력

출구 압력

게이지

입구 커넥터

콘센트 커넥터

옵션

SR1

B

D

F

G

00

00

P

SR1L

(316L)

SR1B

(강철 전기도금)

A

B

D

G

J

M

Q

C:4000psi

D:3000psi

F:500psi

F:0-500psi

G:0-250psi

1:0-100psi

K:0-50psi

L:0-25psi

Q:30'HgVac-30psi

S:30'HgVac-60psi

T:30"HgVac-100psi

U:30"HgVac-200psi

G: MPa 테이블

P: Psi/bar 테이블

W: 압력계 없음

00:1/4"NPT(F)

01:1/4"NPT(M)

23:CGA330

24:CGA350

27:CGA580

28:CGA660

30:CGA590

52:G5/8"-RH(F)

63:W21.8-14RH(에프)

64:W21.8-14LH(에프)

다른 형태의 커넥터도 사용 가능

선택

00:1/4"NPT(F)

01:1/4"NPT(M)

10: 1/8" 카드 슬리브 커넥터

11: 1/4" 카드 슬리브 커넥터

12: 3/8" 카드 슬리브 커넥터

15: 6mm 카드 슬리브 커넥터

16: 8mm 카드 슬리브 커넥터

74:M8x1RH(M)

다른 형태의 커넥터도 사용 가능

선택

P: 패널 설치

R: 안전 밸브

N: 니들 밸브

D: 다이어프램 밸브
