SR6 시리즈 스테인리스강 초대형 유량 압력 조절기

/ 제품 / 스테인레스 스틸 압력 조절기 / SR6 시리즈 스테인리스강 초대형 유량 압력 조절기

SR6 시리즈 스테인리스강 초대형 유량 압력 조절기

산업용 등급의 ​​대용량 애플리케이션을 위해 특별히 설계된 SR6은 전체 SR 시리즈 중 유량 용량의 정점을 나타내는 5.1의 놀라운 CV 값을 자랑합니다. 이러한 높은 유량을 지원하기 위해 입구 및 출구 포트는 균일한 3/4" NPT(F)이며, 니트릴 고무를 밸브 시트 재료로 사용하고 나일론으로 라이닝된 복합 다이어프램을 사용하여 초고유량을 유지하면서 뛰어난 밀봉 탄력성을 보장합니다. 전체 무게가 6kg으로 시스템의 안정적인 노드가 되어 최대 입력 압력의 1.5배에 달하는 충격을 견딜 수 있으며 대규모 공정 제어 시스템 및 가스 매니폴드에 널리 사용됩니다. 석유화학 산업.

  • 설명
  • 문의하기

시리즈

보시 포트

입구 압력

출구 압력

게이지

입구 커넥터

콘센트 커넥터

SR6

B

F

G

G

06

06

SR6L

(316L)

SR6B

(구리 전기도금)

A

B

D

G

F:500psi

G:0-250psi

H:0-125psi

1:0-100psi

K:0-50psi

L:0-25psi

G: MPa 테이블

P: Psi/bar 테이블

W: 압력계 없음

06:3/4"NPT(여)

07:3/4"NPT(M)

08:1"NPT(여)

09:1"NPT(M)

다른 형태의 커넥터도 선택할 수 있습니다.

06:3/4"NPT(여)

07:3/4"NPT(M)

08:1"NPT(여)

09:1"NPT(M)

다른 형태의 커넥터도 선택할 수 있습니다.
